13 000 ₽

MXX

Name: MXX
Brand: CATOFF
SKU: 22a932d
Price: 13000 RUB
Availability: InStock

audio mixer with cv-panning

CATOFF

Great for percussion mixing but not just for that

5 input mono-channels with CV pan-control

The six stereo-input IN-6S can be used for any external synthesizer, sampler or drum-machine

Outputs for Left and Right line outs + stereo headphones output

MXX can be used as VCA. It's enough to twist the PAN to the far position and send the control voltage to the PAN CV

TECHNICAL SPECIFICATIONS

Frequency Response: 20Hz to 20kHz +/-0.5dB Input 1-5 Gain: 0db Input 1-5 Impedance: 100kΩ Input 1-5 Maximum Level: +20dBu (-/+10V) Stereo Input 6 Gain: +22db Stereo Input 6 Impedance: 20kΩ Stereo Input 6 Maximum Level: +12dBu Input CV Impedance: 100kΩ Input CV Optimal Level (for full range panning): -/+5V Left & Right Output Impedance: 1kΩ per channel Headphones Output Impedance: 470Ω Left & Right Output Maximum Level: +20dBu Headphones Output Maximum Level: +5dBu / at 100Ω# 200mW (for 100Ω headphones) Power Usage: 68mA# +12v / 43mA# -12v Width: 12HP Depth: 21mm max from the back side of the front panel

Stock
YES

Great for percussion mixing but not just for that

The six stereo-input IN-6S can be used for any external synthesizer, sampler or drum-machine

MXX can be used as VCA. It's enough to twist the PAN to the far position and send the control voltage to the PAN CV

5 input mono-channels with CV pan-control

Outputs for Left and Right line outs + stereo headphones output
